Transparent Medical Instrument PN-1500 (1*4) / Two-plates mold / Cold runner No.21062-B

Product Categories

Dongguan Chitwing Technologies Co., Ltd

Contact Now

Name: Transparent Medical Instrument PN1500 14 Twoplates mold Cold runner No21062B
Brand: Chitwing
Price: 1 USD

Brand Name : Chitwing

Model Number : VR Products

Certification : ISO 9001:2015

Place of Origin : China

MOQ : 1set

Price : Negotiable

Payment Terms : L/C, T/T

Supply Ability : 200 set/month

Delivery Time : 30 day(s)

Packaging Details : The mold is packaged with a wooden box and placed on a wood pallet.

Size : 250.000 X 250.000 X 251.000

IMM Tonnage : 100T

Mold Weight : 94kg

Standard mold base : CI2025.507070

Standard : LKM

Part material : POM

Part net weight : 0.03g

Contact Now

Transparent Medical

Instrument PN-1500 (1*4)

No.21062-B

The mold brand is Chitwing, manufactured in Guangdong, China, and is designed for a

100T injection molding machine. The mold surface is polished to SPI B-2, and the cavity

and core are hardened using 1*4/S136, providing better smoothness, higher hardness,

corrosion resistance, and wear resistance. This prevents POM from sticking to the mold,

allowing for easy demolding and smooth part surfaces. The tool life is greatly extended

(up to 500k shots), making it suitable for mass production. The mold is well-fitted and

free of flow marks and gas marks.

Transparent Medical Instrument PN-1500 (1*4) / Two-plates mold / Cold runner No.21062-B

Transparent Medical Instrument PN-1500 (1*4) / Two-plates mold / Cold runner No.21062-B

Part Length	Part Width	Part Height
3.86 mm	7.78 mm	3.25 mm

Transparent Medical Instrument PN-1500 (1*4) / Two-plates mold / Cold runner No.21062-B

Display diagram

Transparent Medical Instrument PN-1500 (1*4) / Two-plates mold / Cold runner No.21062-B Images
